Urban life on the Papierbach - Quartier 3
Location:
Landsberg am Lech
Completion:
2026
Urban life on the Papierbach - Quartier 3
Location Von-Kühlmann-Straße 25 in Landsberg am Lech
The "Urban Living on Papierbach - Quartier 3" project in Landsberg am Lech comprises several residential buildings with restaurants on the first floor .
Access to the restaurant is via Europa-Platz. The project is divided into the two construction sites B3 and C.
A two-storey underground car park is being built under both construction sites, which is accessible via an entrance and exit ramp via Von-Kühlmann-Straße.
A total of 60 privately financed apartments are being built in construction site B3 and 107 mostly subsidized apartments in construction site C.
The excavation pit was constructed on three sides with sheet piling and on one side with a bored pile wall by the client. The shell of the building will be constructed largely with prefabricated brick elements or STB-FT where possible. The façade is given an external render with partial clinker brick slips. The non-load-bearing interior walls will be constructed as lightweight walls in plasterboard stud construction.
The building will be built to KfW Efficiency House Standard 55 in accordance with the BEG.
The majority of the entrances will be barrier-free on the outside. All apartments in the main buildings will be accessible without steps by elevator, and the terraces and balconies will also be barrier-free. Access to the underground parking garage will be barrier-free.
-
Construction site camera
-
Characteristics
- Plot area (GF): 9,699 m²
- Developed area: approx. 7,950 m²
- Gross floor area (GFA): 111,668.97 m³
- C 64,290.29 m³
- B3 47,378.68 m³ - Gross floor area (GFA): 327,243.97 m²
- C 11,665.86 m²
- B 15,578.11 m² - Above ground: 3-4 full storeys
- Underground: 2-storey underground parking garage
-
Construction time
- Construction site installation from 15.04.2024
- Structural work
- C 05 / 2024 to 09 / 2025
- B3 05 / 2024 to 09 / 2025 - Building envelope
- C 08 / 2025 to 02 / 2026
- B3 07 / 2025 to 11 / 2025 - Expansion
- C 09 / 2025 to 06 / 2026
- B3 08 / 2025 to 06 / 2026 - Completion
- B3 & C 07 / 2026
-
Construction site regular operation
- Monday to Friday 07:00 to 18:00
- Saturday 07:00 to 15:00
- There is generally no work on Sundays and public holidays.
Certified by the German Sustainable Building Council (DGNB)
Ed. Züblin AG is pursuing several goals with this project: A sustainable construction site organization, the conservation of resources as well as the minimization of emissions, responsibility for the health and well-being of the builders, the cultivation of good neighbourliness and, of course, high-quality construction. For this, Ed. Züblin AG was the first company to be recognized by the German Sustainable Building Council (DGNB).
Here you can find more information about the DGNB system for sustainable construction sites: https://www.dgnb.de/en/certification/buildings/construction-site
Selected measures in the project
-
Finished parts
The extensive use of prefabricated parts (prefabricated brick parts, balconies, loggias and stairs) means that a shorter construction time can be achieved. The volume of waste is also reduced thanks to the prefabricated orders.
-
Saving resources and reducing emissions through LEAN Construction
As part of the lean approach, a production plan with call-off dates (e.g. insulation) was drawn up. Construction production planning is detailed as required and adapted to actual production progress. Changes in the construction process are constantly taken into account and just-in-time deliveries can be better implemented. When used on the construction site, the aim is to complete all services on time, to the planned quality and at the calculated cost.
-
Digital concrete call-off
In order to be able to coordinate the concreting in the best possible way, the call-offs are made using a digital application. Particularly in the case of large-scale concreting, the delivery quantities can be coordinated with the concrete pump, thus reducing the waiting times of the concrete mixers. Production times are optimized and noise emissions are reduced.
-
Measures to prevent pollution from the construction site
The project is located in the city center, so the impact of the construction site will be avoided or reduced as much as possible.
-
Digitalization of the construction process
The BIM and document management application DALUX is used to digitalize the construction process, which helps to reduce the use of paper by digitalizing processes, among other things. The platform is used for daily construction reports, photo documentation, trade checklists and defect management with subcontractors. Each defect or documentation point can be located accordingly in the imported 3D model. The tool saves time and resources and simplifies processes on the construction site.
-
Regional companies and suppliers
Where possible, mainly regional companies and suppliers are used in order to reduce transportation and working distances.
| Certification contact person | Valerie Sartorius |
| Project contact | Tobias Gundel |
| Construction site address | Von-Kühlmann-Straße 25 86899 Landsberg am Lech Phone +49 821 440174-0 Ed. Züblin AG Subdivision Ulm - Augsburg unit |
| Download | Press release |
| Link | DGNB: Certification Client: https://ampapierbach-landsberg.de/ |
